SlimKIC-2000 temperature tester
| Categories | Temperature Control |
|---|---|
| Brand | SAMTRONIK |
| Model | SlimKIC-2000 |
| Accuracy | ±1.2°C |
| Resolution | Variable 0.3 to 0.1°C |
| Internal Operating Temp | 0°C to 105°C |
| Thermocouple Compatibility | Type K, 9 or 12 TCs |
| Temperature Range | -150°C to 1050°C |
| Power Requirements | 9V alkaline battery |
| Thermal Receiver | 433.92 MHz |
| Update Time | Nov 15,2024 |
Detail Information
SlimKIC-2000
SlimKIC
2000 Profiling is Easy
By automating the complex task of process set up
the SlimKIC® 2000 makes profiling so easy that any operator can quickly achieve
the optimal process. Simply select from a built-in library containing hundreds
of commonly used solder paste specifications. The software uses the paste
supplier’s thermal profile specs to automatically define the process window.
Color-coded signals alert the operator to any out-of-specification conditions.
SlimKIC
2000 Profiling is Fast
The SlimKIC 2000 features innovative, patent pending technology that virtually eliminates the time consuming tasks traditionally associated with temperature profiling. Oven zones and mapping of thermocouples on the product are automated. Process acceptability is instantly determined, reducing the number of required profile runs and minimizing production downtime.
Technical Specifications
|
Accuracy |
±1.2°C |
|
Resolution |
Variable 0.3 to 0.1°C |
|
Internal Operating Temp |
0°C to 105°C |
|
Thermocouple Compatibility |
Type K, 9 or 12 TCs |
|
Temperature Range |
-150°C to 1050°C |
|
Computer Capability |
PC |
|
Power Requirements |
9V alkaline battery |
|
Thermal Receiver |
433.92 MHz |
|
Dimensions |
See Temperature Tolerance Chart below for specifications. |
